Home  >> Piezo Buzzer > External Drive > AZ-1440E-P



External Drive Self Drive SMD Element

Piezo Buzzer

Piezo Buzzer

Items   Units Specifications Conditions
1 Rated Voltage Vp-p 5 (square wave)
2 Operating Voltage Vp-p 1.0~20.0
3 Rated Current mA(Max) 5
4 Sound Output At 10cm dBA(Min) 80
5 Resonant Frequency Hz 4000±500
6 Capacitance at Frequency pF 13000±30%
6 Operating Temp. ℃ -20 ~ +70
7 Storage Temp. ℃ -30 ~ +80
8 Weight g 1















Data Sheet
