Home  >> Piezo Buzzer > External Drive > AZ-2320E-P



External Drive Self Drive SMD Element

Piezo Buzzer

Piezo Buzzer

Items   Units Specifications Conditions
1 Rated Voltage Vp-p 10 Square Wave
2 Operating Voltage Vp-p 3~30
3 Rated Current mA(Max) 9 At 10 Vp-p
4 Sound Output At 10cm dBA(Min) 85 At 10 Vp-p
5 Resonant Frequency Hz 2048±500
6 Capacitance at 120Hz pF 24000±30%
7 Operating Temp. -20 ~ +70
8 Storage Temp. -30 ~ +80
9 Weight g 2















Data Sheet
