Home  >> Piezo Buzzer > Self Drive > AZ-1440S-P



External Drive Self Drive SMD Element

Piezo Transducer

Piezo Buzzer

Items   Units Specifications Conditions
1 Rated Voltage VDC 12
2 Operating Voltage VDC 3.0~16.0
3 Rated Current (Max) mA 7 At 12 VDC
4 Min Sound Output dBA 80 At 12VDC
5 Resonant Frequency Hz 4000±500
6 Tone Nature   Single
7 Operating Temp. ℃ -20 ~ +60
8 Storage Temp. ℃ -30 ~ +70
9 Weight g 1















Data Sheet
