Home  >> Piezo Buzzer > Self Drive > AZ-2335S-W



External Drive Self Drive SMD Element

Piezo Transducer

Piezo Buzzer

Items Units Specifications Conditions
1 Rated Voltage VDC 12
2 Operating Voltage VDC 3~24
3 Rated Current mA(Max) 10 At 12VDC
4 Sound Output At 30 cm dBA(Min) 80 At 12 VDC
5 Resonant Frequency Hz 3500±500
6 Tone Nature Single
7 Operating Temp. -20 ~ +60
8 Storage Temp. -30 ~ +70
9 Weight g 3.5















Data Sheet
