Buzzer manufacturer   A & B Components Co. Ltd.

Home  >> Piezo Buzzer > Self Drive > AZ-4329S-FP



External Drive Self Drive SMD Element

Piezo Transducer

Piezo Buzzer

Items   Units Specifications Conditions
1 Rated Voltage VDC 12
2 Operating Voltage VDC 4~28
3 Rated Current mA(Max) 8 At 12 VDC
4 Sound Output At 30 cm dBA(Min) 78 At 12 VDC
5 Resonant Frequency Hz 2900±500
6 Tone Nature SLOW PULSE (1.2Hz)
7 Operating Temp. ℃ -30 ~ +85
8 Storage Temp. ℃ -40 ~ +85
9 Weight g 32















Data Sheet
