Items |
Units |
Specifications |
| 1 |
Rated Voltage |
Vo-p |
3.6 |
| 2 |
Operating Voltage |
Vo-p |
3 ~ 4.5 |
| 3 |
Consumption Current |
mA |
90(max) |
| 4 |
Sound Pressure Label |
dB |
87(min) |
| 5 |
Resonant Frequency |
Hz |
2700 |
| 6 |
Coil Resistance |
Ω |
16 ± 3 |
| 7 |
Operating Temp. |
℃ |
-20 ~ +60 |
| 8 |
Storage Temp. |
℃ |
-30 ~ +70 |
| 9 |
Weight |
Gram |
0.8 |
