| Items |
|
Units |
Specifications |
Conditions |
| 1 |
Rated Voltage |
Vo-p |
3.6 |
Vo-p |
| 2 |
Operating Voltage |
Vo-p |
2.5~4.5 |
0V |
| 3 |
Consumption Current |
mA |
Mean 100 |
Standard State, Standard Drive Circuit. |
| |
|
(max) |
Peak 300 |
Rated Voltage,Rated Frequency ,Distance |
| 4 |
Sound Output |
dB |
90 (min) |
at 10 cm free air,Square Wave 1 / 2 Duty |
| 5 |
Rated Frequency |
Hz |
4000 |
|
| 6 |
Coil Resistance |
Ω |
16 ± 3 |
At Basic State |
| 7 |
Operating Temp. |
℃ |
-30 ~ +75 |
|
| 8 |
Storage Temp. |
℃ |
-40 ~ +85 |
|
| 9 |
Weight |
Gram |
0.6 |
|
