| Items |
|
Units |
Specifications |
Conditions |
| 1 |
Rated Voltage |
Vp-p |
3 |
|
| 2 |
Operating Voltage |
Vp-p |
3-25 |
|
| 3 |
Rated Current (Max) |
mA |
5 |
At 3Vp-p / 2KHz |
| 4 |
Min Sound Output |
dB |
70 |
At 10cm / 2KHz |
| 5 |
Resonant Frequency |
Hz |
2000±500 |
|
| 6 |
Capacitance at 120Hz |
pF |
34000±35% |
|
| 7 |
Lead Wire / Lead pin Material |
Phosphor Bronze |
|
|
| 8 |
Operating Temp. |
℃ |
-20 ~ +70 |
|
| 9 |
Storage Temp. |
℃ |
-40 ~ +85 |
|
| 10 |
Weight |
g |
1 |
|
