Home  >> Piezo Buzzer > External Drive > AZ-2332E-A



External Drive Self Drive SMD Element

Piezo Buzzer

Piezo Buzzer

Items   Units Specifications Conditions
1 Rated Voltage VDC 12
2 Operating Voltage VDC 3 ~ 20
3 Rated Current mA(Max) 12
4 Sound Output At 30cm dBA(Min) 80 At 12VDC / 3.2KHz
5 Resonant Frequency Hz 3200±500
6 Operating Temp. ℃ -20 ~ +85
7 Storage Temp. ℃ -30 ~ +95
8 Weight g 1.3















Data Sheet
