| Items |
|
Units |
Specifications |
Conditions |
| 1 |
Rated Voltage |
Vp-p |
6 |
(square wave) |
| 2 |
Operating Voltage |
Vp-p |
3~20 |
|
| 3 |
Rated Current |
mA(Max) |
8 |
|
| 4 |
Sound Output Level |
dBA(Min) |
85 |
At 6Vp-p ,4.4KHz / 10cm |
| 5 |
Resonant Frequency |
Hz |
4400±500 |
|
| 6 |
Capacitance |
pF |
25000±30% |
At 120Hz |
| 7 |
Operating Temp. |
℃ |
-20 ~ +60 |
|
| 8 |
Storage Temp. |
℃ |
-30 ~ +70 |
|
| 9 |
Weight |
g |
1 |
|
