| Items |
|
Units |
Specifications |
Conditions |
| 1 |
Rated Voltage |
Vp-p |
12 |
Square Wave |
| 2 |
Operating Voltage |
Vp-p |
3~30 |
|
| 3 |
Rated Current |
mA(Max) |
15 |
12Vp-p / 2.5KHz |
| 4 |
Sound Output At 10cm |
dBA(Min) |
80 |
At 12Vp-p / 2.5KHz |
| 5 |
Resonant Frequency |
Hz |
2500±500 |
|
| 6 |
Capacitance at 120Hz |
nF |
35±30% |
|
| 7 |
Operating Temp. |
℃ |
-20 ~ +60 |
|
| 8 |
Storage Temp. |
℃ |
-30 ~ +70 |
|
| 9 |
Weight |
g |
3.5 |
|
