| ITEM |
|
CONDITION |
| 1 |
Type. |
EXTERNAL -drive type sound element |
| 2 |
Resonant Frequency (KHz) |
2.9± 0.5 at 25± 2℃, 45~60% RH |
| 3 |
Resonant Impedance (OHM) |
350 OHM Max. at 25± 2℃, 45~60% RH |
| 4 |
Capacity (PF) |
30000±30% at 1.0KHz 1Vrms |
| 5 |
Plate Material |
BRASS |
| 6 |
Lead Wire Spec. |
Awg 28, UL 1095 |
| 7 |
Operating Temperature (℃) |
-20 to +60 |
| 08 |
Storage Temperature (℃) |
-20 to +70 |
