Home  >> Piezo Buzzer > Self Drive > AZ-2245S-W



External Drive Self Drive SMD Element

Piezo Transducer

Piezo Buzzer

Items   Units Specifications Conditions
1 Rated Voltage VDC 12
2 Operating Voltage VDC 3.0-30.0
3 Rated Current (Max) mA 7
4 Min Sound Output dBA 85 at 30cm
5 Resonant Frequency Hz 4500±500
6 Operating Temp. ℃ -20 ~ +60
7 Storage Temp. ℃ -30 ~ +70
8 Tone Nature   SINGLE
9 Weight g 4















Data Sheet
