Home  >> Piezo Buzzer > Self Drive > AZ-2331S-W



External Drive Self Drive SMD Element

Piezo Transducer

Piezo Buzzer

Items   Units Specifications Conditions
1 Rated Voltage VDC 12
2 Operating Voltage VDC 3~16
3 Rated Current mA(Max) 8 At 12VDC
4 Sound Output At 30cm dBA(Min) 80 At 12VDC
5 Resonant Frequency Hz 3100 ± 500
6 Tone Nature   Single
7 Operating Temp. ℃ -20 ~ +60
8 Storage Temp. ℃ -30 ~ +70
9 Weight g 5















Data Sheet
