Home  >> Piezo Buzzer > Self Drive > AZ-3027S-P



External Drive Self Drive SMD Element

Piezo Transducer

Piezo Buzzer

Items   Units Specifications Conditions
1 Rated Voltage VDC 12
2 Operating Voltage VDC 3~20
3 Rated Current mA(Max) 10 At 12 VDC
4 Sound Output At 30 cm dBA(Min) 85 At 12 VDC
5 Resonant Frequency Hz 2700±500
6 Tone Nature   Single
7 Operating Temp. ℃ -20 ~ +60
8 Storage Temp. ℃ -20 ~ +70
9 Weight g 3















Data Sheet
