Home  >> Piezo Buzzer > Self Drive > AZ-3032S-P



External Drive Self Drive SMD Element

Piezo Transducer

Piezo Buzzer

Items   Units Specifications
1 Rated Voltage VDC 12
2 Operating Voltage VDC 3~20
3 Rated Current mA(Max) 10
4 Sound Output At 10cm dBA(Min) 90
5 Resonant Frequency Hz 3200±500
6 Operating Temp. ℃ -20 ~ +60
7 Storage Temp. ℃ -30 ~ +70
8 Tone Nature   Single
9 Weight g 11















Data Sheet
