Home  >> Piezo Buzzer > Self Drive > AZ-4229S-GJB



External Drive Self Drive SMD Element

Piezo Transducer

Piezo Buzzer

Items   Units Specifications Conditions
1 Rated Voltage DC/AC 110
2 Operating Voltage DC/AC 30-120
3 Rated Current mA(Max) 18 At 110 DC/AC
4 Sound Output At 30cm dBA(Min) 83 At 110 DC/AC
5 Resonant Frequency Hz 2900±500
6 Operating Temp. ℃ -20 ~ +60
7 Storage Temp. ℃ -30 ~ +70
8 Tone Nature   Single
9 Weight g 34















Data Sheet
