Home  >> Piezo Buzzer > Self Drive > AZ-4329S-W



External Drive Self Drive SMD Element

Piezo Transducer

Piezo Buzzer

Items   Units Specifications Conditions
1 Rated Voltage VDC 12
2 Operating Voltage VDC 3~20
3 Rated Current mA(Max) 60 At 12VDC
4 Sound Output At 10cm dBA(Min) 105 At 12VDC
5 Resonant Frequency Hz 2900±500
6 Tone Nature Single
7 Operating Temp. ℃ - 20 ~ +60
8 Storage Temp. ℃ - 30~ +70
9 Weight g 43















Data Sheet
